Pressure range: 10-2000KG
Pressure accuracy: ±0.5%
Speed: 0-60mm/s
Position accuracy: ±0.005mm
Using a touch screen and a single-chip microcomputer, all I/O or drive pressure sensors are connected by an aviation plug.
Reserved RS485 or Ethernet communication interface (optional)
Terminal devices such as printers, scanners and RF devices (optional) can be connected via USB.
The parameters of the production can be linked to the SFCS for production control (optional).
Good anti-interference ability, external high-frequency, ultrasonic, laser, magnetizer and other equipment.

● Effective stroke: 200mm
● Maximum pressure: Nominal 2000KG
● Maximum speed: It adopts advanced servo pressure drive, the idle speed is above 10MM/sec, and the working speed is 20 MM/sec.
● Motion accuracy: ±0.01mm
● Repeatability: ±0.01mm
  The riveting pressure is set in sections to accurately control the riveting pressure of each time (see below)
  Riveting depth distance has a variety of distance setting riveting mode, function selection (see below)
● Transmission mechanism: servo drive system
● Programming interface: LCD touch screen
● Controller: Servo hydraulic program controller
● Input power: three-phase 380VAC, 50-60HZ, 5KW
● Input air pressure: 5~7.0 Kgf/CM2
● Machine weight: 800Kg
● Dimensions: (W*D*H) 1090*950*1650mm (subject to actual)
